FireFlo OMNI

A webhook endpoint is an https:// address on your server that OMNI tells about what happened. Add endpoints in Developer Tools → Webhooks, or with POST /v1/webhooks; each asks for the events it wants, or * for all of them, including events added later.

The webhooks screen, listing endpoints with their events and whether each is working — Developer Tools → Webhooks

What arrives

Each delivery is one POST with a JSON body:

{
  "id": "evt_6f1c0a3b9d2e4f7a8b6c5d4e3f2a1b0c",
  "event": "message.succeeded",
  "created": "2026-10-05T11:42:11.902Z",
  "data": { "message": { "id": "msg_4f1c…", "status": "succeeded", … } }
}

and these headers:

Header
`X-FireFlo-Signature`	`t=<unix seconds>,v1=<hex>` — see below
`X-FireFlo-Event`	The event, e.g. `message.succeeded`
`X-FireFlo-Delivery`	This delivery’s id — the same on every retry of it
`User-Agent`	`FireFlo-OMNI-Webhooks/1`

Answer with any 2xx within 10 seconds. Do slow work after answering. Redirects are not followed.

Checking the signature

Every delivery is signed with the endpoint’s secret (whsec_…, shown once when the endpoint is made, or when you make a new one). The signature is the HMAC-SHA256, in hex, of "<t>.<body>" — the timestamp, a full stop, and the raw body exactly as received. Check it before trusting the body, and refuse deliveries whose t is more than a few minutes old:

import hashlib, hmac, os, time

def verify(raw_body: bytes, header: str, secret=os.environ["OMNI_WEBHOOK_SECRET"]) -> bool:
    parts = dict(part.split("=", 1) for part in header.split(","))
    t, given = parts.get("t", ""), parts.get("v1", "")
    if not t.isdigit() or abs(time.time() - int(t)) > 300:
        return False
    expected = hmac.new(secret.encode(), f"{t}.".encode() + raw_body, hashlib.sha256).hexdigest()
    return hmac.compare_digest(expected, given)

import { createHmac, timingSafeEqual } from "node:crypto";

export function verify(rawBody, header, secret = process.env.OMNI_WEBHOOK_SECRET) {
  const parts = Object.fromEntries(header.split(",").map((part) => part.split("=")));
  if (!/^\d+$/.test(parts.t ?? "") || Math.abs(Date.now() / 1000 - Number(parts.t)) > 300) return false;
  const expected = createHmac("sha256", secret).update(`${parts.t}.`).update(rawBody).digest("hex");
  return expected.length === (parts.v1 ?? "").length && timingSafeEqual(Buffer.from(expected), Buffer.from(parts.v1));
}

function verify(string $rawBody, string $header, string $secret): bool {
    parse_str(str_replace(',', '&', $header), $parts);
    $t = $parts['t'] ?? '';
    if (!ctype_digit($t) || abs(time() - (int) $t) > 300) return false;
    $expected = hash_hmac('sha256', $t . '.' . $rawBody, $secret);
    return hash_equals($expected, $parts['v1'] ?? '');
}

require "openssl"

def verify(raw_body, header, secret = ENV["OMNI_WEBHOOK_SECRET"])
  parts = header.split(",").map { |part| part.split("=", 2) }.to_h
  t = parts["t"].to_s
  return false unless t.match?(/\A\d+\z/) && (Time.now.to_i - t.to_i).abs <= 300
  expected = OpenSSL::HMAC.hexdigest("SHA256", secret, "#{t}.#{raw_body}")
  OpenSSL.secure_compare(expected, parts["v1"].to_s)
end

Use the raw body bytes. A body parsed and re-encoded by your framework will not match.

Retries, and an endpoint switched off

A delivery not answered 2xx is tried again after 30 seconds, 5 minutes, 30 minutes, 2 hours and 12 hours, then given up. An endpoint that has failed for three days without a single success is switched off, and says so in the panel; switch it back on once it’s fixed. Deliveries can arrive more than once and out of order. Use X-FireFlo-Delivery (or the event’s id) to ignore a repeat, and the times in data rather than arrival order. Every endpoint’s deliveries — each event, its answer and its tries — are in Developer Tools → Webhooks → the endpoint, where any of them can be sent again, and in GET /v1/webhooks/{endpoint_id}/deliveries. Send a test sends a webhook.test event at once.

Events

A message, with failover

data.message is the message as GET /v1/messages/{message_id} shows it, with every attempt.

Event	When
`message.attempted`	A step handed the message to a channel
`message.failed_over`	A step didn’t get there; the next one is trying
`message.succeeded`	A step reached its goal (`outcome` says which channel, and how far)
`message.failed`	Every step was tried, or the person may not be reached
`message.expired`	It ran out of time before it got there
`message.canceled`	It was canceled

A message on a channel

Every message any channel carries — sent through the API, a broadcast, the Inbox or an AI agent. data.channel_message:

{
  "id": "cm_88123",
  "channel": "sms",
  "direction": "outbound",
  "to": "+919876543210",
  "from": "FIRFLO",
  "status": "delivered",
  "text": "Hi Ravi, your order A-1043 has shipped.",
  "error": "",
  "campaign": null,
  "created": "2026-10-05T11:42:07.164Z",
  "status_at": "2026-10-05T11:42:11.902Z"
}

Event	When
`channel_message.received`	Someone sent you a message, on any channel
`channel_message.sent`	A message was handed to its channel
`channel_message.delivered`	It reached the phone
`channel_message.read`	It was read
`channel_message.failed`	It couldn’t be delivered

A call

data.call is the call as GET /v1/calls/{call_id} shows it, with its channel.

Event	When
`call.started`	A call started, either way
`call.answered`	It was answered
`call.ended`	It ended after being answered
`call.failed`	A call you placed wasn’t answered
`call.missed`	A call rang in and nobody took it

Testing

webhook.test — sent only when you ask, with data.endpoint naming the endpoint.
